4.2. ELECTRICAL SPECIFICATIONS FOR STANDARD MOTORS
Motors - 230 V / 1 ph / 50 Hz / 60 Hz
Electric heating resistances - 230 V / 1 ph / 50 Hz / 60 Hz
(*) Current and power drawn by the motor in operation at 230 V / 1 Ph / 50 Hz, unit not tted with ducting
and with 0 Pa pressure available for a unit with a G3 lter. Rectangular duct inlet and outlet
(*) Current and power drawn by the motor in operation at 230 V / 1 Ph / 50 Hz, unit not tted with ducting
and with 0 Pa pressure available for a unit with a G3 lter. Circular duct inlet and outlet.
4.3. ELECTRIC HEATING RESISTANCES
Unit size
VH07 VH15 VH18
Current
absorbed
(A) *
Power
absorbed
(w)*
Current
absorbed
(A) *
Power
absorbed
(w)*
Current
absorbed
(A) *
Power
absorbed
(w)*
Speed
V1
0.66 132 0.93 180 0.93 180
V2
0.75 163 1.33 271 1.33 271
V3
0.82 182 2.00 421 2.00 421
V4
0.88 201 2.52 587 2.52 587
V5
0.98 222 3.17 675 3.17 675
Unit size
VH21 VH24 VH27
Current
absorbed
(A) *
Power
absorbed
(w)*
Current
absorbed
(A) *
Power
absorbed
(w)*
Current
absorbed
(A) *
Power
absorbed
(w)*
Speed
V1
0.93 180 2.00 420 2.00 420
V2
1.33 271 2.40 530 2.40 530
V3
2.00 421 3.00 673 3.00 673
V4
2.52 587 3.85 870 3.85 870
V5
3.17 675
Unit size
Capacity (W)
BE1 BE2 BE3
VH07
1000 1500 2000
VH15 / VH18 / VH21
1000 2000 3000
VH24 / VH27
1000 2000 3000
SEE APPENDIX
