Systembuild Evolution 7532196COM - Step 5: Connecting Frame Sections

5.1 Attach (L) to (B) with (1) as illustrated.
5.2 Attach (M) to (C) with (1) as illustrated.
5.3 Attach (H) to (F) with (1) as illustrated.
5.4 Use (13) to cover cam lock hole as illustrated.
STEP 5
11
Tube
You
Proper orientation of CAM LOCK
Tip
Quick
Assembly
UNLOCK
LOCK
×10
1
13
systembuild.com
×6
F
H
B
L
C
M
1
13
