Systembuild Evolution 7532196COM - Step 10: Door and Hardware Attachment

STEP 10
16
Tube
You
10.1 Attach (J) to sub-assembly A/B/C/F from previous step with (11) as illustrated.
10.2 Attach (7) to (J) with (5) as illustrated.
10.3 Attach (15) to (J) with (4) as illustrated.
systembuild.com
×4
4
15
×2 ×12
11
×85 ×4
7
J
15
4
J
J
7
5
11
C
B
