Systembuild Evolution 7532196COM - Step 8: Back Panel Attachment

STEP 8
14
Tube
You
8.1 Attach (N) to sub-assembly A/B/C/F from previous step with (8) as illustrated.
Important: Assure that the unit is square. Distance from corner to corner must be
equal as shown.
systembuild.com
×308
IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART
OF THIS UNIT AND MUST BE INSTALLED PROPERLY.
F
C
B
N
A
Raw material side
