POWERPAC ASSEMBLY 725 RV
P O W E R A M P
M C G U I R E
D L M
S Y S T E M S, I N C.
L o a d i n g D o c k E q u i p m e n t
This print is the property of Systems, Inc. and represents a proprietary article in which Systems, Inc. retains any and all
patent and other rights, including exclusive rights of use and/or manufacture and/or sale. Possession of this print does
not convey any permission to reproduce, print or
manufacture the article or articles shown therein, such permission to be
granted only by written authorization signed by an officer or other authorized agent of Systems, Inc. thereof.
STOCK NO.
A
A
BILL OF MATERIAL
SIZEDESCRIPTIONPART NO.QTYITEM
3/8CONECTOR - 2 SCREW
1431-001111
16-14 AWGINSULATED TERMINALS1431-008632
1-5/8 X 4-7/8DECAL, NO STEP
1751-014913
115V,1PH,60HZDECAL, 1751-0113 W/TEXT1751-021014
3/8-16 UNC X 1HHCS - GRADE 2 - ZINC PLATED
2101-001725
3/8LOCK WASHER2101-014026
1-3/8 OD X 3/4 IDGROMMET
2401-000127
4 X 4COVER, J-BOX2751-001618
64-77mf - 330VCAPACITOR - MOTOR START
3051-005819
#4 ORBM,#4 JICM,SAE#070320FTG,ELBOW,45 DEG,STR THRD9301-0221210
B CADPOWERPAC MOUNTING WELDMENT
9391-0012111
B CADCOVER - P
OWERSTOP9391-0013112
1/4HP,0.60 GPM,1PH,115/230VPPAC,STOP STYLE RSTRNT, 725 RV
9391-0070113
#4 JICF SWIVEL BOTH ENDSHYD HOSE,1/4"100R17,180.00 LG 9904-0098REF14
#4 JICF SWIVEL BOTH ENDSHYD HOSE,1/4"100R17,96.00 LG
9904-0119REF
TINT REDFLUID,HYD,ULTRA VIS HVI 15R507-0001REF15
16 GA RED X 5.00"
WIRER513-0050116
1/4" X 9.00"SPLIT FLEX CONDUITR598-0090217
B B
TOLERANCES
(UNLESS OTHERWISE NOTED)
FRACTIONAL:
1/32"
DECIMAL:
.00 =
.01"
.000 =
.005"
ANGULAR:
1
DRAWN BY
CHECKED BY
DRAWING NO.
DATE
BDK
10/11/2017
9395-0407
POWERPAC ASSEMBLY 725 RV
L o a d i n g D o c k E q u i p m e n t
P O W E R A M P
D L M
This print is the property of Systems, Inc. and represents a proprietary article in which Systems, Inc. retains any and all pat ent and other rights, including exclusive rights
of use and/or manufacture and/or sale. Possession of this print does not convey any permission to reproduce, print or manufactu re the article or articles shown therein,
such permission to be
granted only by written authorization signed by an officer or other authorized agent of Systems,Inc. ther eof.
POWERSTOP-115-1P-PAINTED
9
13/16
REF
16 1/2 REF
7
11
12
5
6
17
1
8
9
RC
BC
HOLE FOR
SEE NOTE 3
HOLE FOR
SEE NOTE 3
BC
RC
10
10
7 1/2
REF
3
4
1315
NOTES:
1. HYDRAULIC CONNECTIONS
"BC" - CONNECT TO BASE END OF RELAY CYLINDER
"RC" - CONNECT TO ROD END OF RELEASE CYLINDER
2. HOSE 9904-0098 - USED FOR REMOTE OR WALL MOUNT
APPLICATIONS.
HOSE 9904-0119 - USED WHEN MOUNTED NEAR
RESTRAINT OR IN LEVELER PIT.
3. FOR PRODUCTION - HYD. FLUID TO BE SHIPPED IN UNIT.
FOR SERVICE - HYD. FLUID TO BE SHIPPED SEPARATE.
-
17-094 10/24/2017
RELEASED FOR PRODUCTION AND
SERVICE. REPLACED 9395-0092
INSTALLATION
• Conduit, flexible or rigid, must be connected
between the limit switch on the restraint and the
Powerpack.
• Wiring to and from the restraint must be limited to
restraint wires only.
• Do not run high voltage lines through the same
conduit as restraint wires.
• Conduit and associated hardware to complete
wiring and mounting of Powerpack are to be supplied
by others.
Connect hydraulic hose to base end of
release cylinder.
Connect hydraulic hose to rod end of release
cylinder.
Powerpack Installation Overview
Figure 20
BC
RC
BC
RC
To Next Page
