PARTS
Item Quantity Part Number Description
1 1 0195-0052 Pstop, Debris Guard Assembly
2 1 0524-0064 Hydraulic Cylinder, 5-3/4” Stroke
3 1 0524-0102 Hydraulic Cylinder, 1” Stroke
4 1 0941-0018 Spring, Compression, 1.937” DIA X 7.402”LG,. 138 Wire
5 1 0941-0021 Spring, Extension, SS, 0.45” DIA X 1.76” LG 0.059 Wire DIA
6 1 0961-0538 Prox SW,AC,Flat, NO,20-250VAC
7 1 0961-0614 Prox Switch, RIG Sensor
8 1 1431-0239 Connector, Tubing, 1/2”, Metal
9 1 1751-0444 Decal - Poweramp/PowerStop
10 1 1751-0735 Decal, Made In Usa
11 1 1751-1252 Decal, Pinch Point
12 1 1751-1290 Decal, Serial Number
13 2 2101-0032 Screw, SHSS,1/4-20 UNC X 3/8”
14 1 2101-0039 Nylon Lock Nut, 5/16-18 UNC
15 1 2101-0089 Screw, HHCS, 3/8”-16 x 2, Grade 2, Zinc Plated
16 3 2101-0151 Nylon Lock Nut, 10-24 UNC
17 2 2101-0156 Washer, Lock #8, Regular Split.
18 8 2101-0189 E-Ring, 1/2”
19 2 2101-0228 Screw, FSHCS, 1/2”-13 UNC x 1
20 1 2101-0335 Screw, Shoulder, 1/2” x 3/8”, Zinc Plated
21 2 2101-0336 Washer, Tag Hole, 1/2”, Stainless Steel
22 2 2101-0349 Retaining Ring, External, Zinc Plated
23 2 2101-0373 Screw, SHCS, 5/16”-18 X 1-3/8”
24 2 2101-0375 Screw, RHMS, TORX, #10-32 X 1/4”
25 2 2101-0376 Screw, RHMS, TORX, #4-40 X 7/8”
26 3 2101-0377 Screw, THMS, TORX, #10-24 X 2.00”
27 2 2101-0388 Screw, PHMS, #6-32 UNC x 5/8”
28 3 3051-0001 Cable Tie
29 2 9202-0042 Pivot Pin, Long, 0.499” DIA X 4.25” LG
30 2 9202-0043 Pivot Pin, Short, 0.499” DIA X 3.00” LG
31 1 9395-0414 Powerpack, Complete (Includes Valve Body and Cover)
32 1 9411-0065 Shroud, Release Cylinder
33 1 9411-0103 Pin, RIG Sensor Bar
34 1 9411-0104 Connection, RIG Sensor Bar
35 1 9411-0105 RIG Sensor Bar
36 1 9411-0107 Spacer, RIG Sensor Bar
37 2 9412-0161 Tube, 1-1/4” OD x 9/16” ID x 0.594”
38 1 9412-0289 Conduit, 1/4”, Split Flex, 35” LG
39 1 9413-0062 Scissor Lift Assembly
40 2 9413-0069 Spacer Assembly, 1-1/8” OD x 11/16” ID x 0.53”
41 1 9413-0121 Lip Deector
42 1
9413-0123 Hook Weldment, Tall Prole (Standard, not shown)
9413-0127 Hook Weldment, Low Prole (Optional)
43 1
9414-0083 Base Weldment, 27
9414-0084 Base Weldment, 24” (Optional, not shown)
44 2 9904-0097 Hydraulic Hose, 1/4 x 24, #4 JICF Swivel Ends
45 2
9904-0119 Hydraulic Hose, 1/4 x 96, #4 JICF Swivel Ends (Standard, not shown)
9904-0098 Hydraulic Hose, 1/4 x 180, #4 JICF Swivel Ends (Optional, not shown)
