3.4 Operating Range of the Machine
The T-DRILL T-60 is intended for forming a tee in copper tube. The branch
tube is joined to the run tube by brazing.
The outlet size range of T-60 is NS 1/2" to 2" (10 – 54 mm).
The diameter of the run tube can be 1/2 " to 4" (15 – 108 mm). The
maximum wall thickness of the tube to be branched depends on the tube
diameter and the size of the T-DRILL head used.
Accurate capacity values: diameters and wall thicknesses of the tube are
specified in the capacity chart (chapter 11.1).
3.5 Technical specifications
T-60 Value NOTE!
Type Code 3305
Tee diameter NS 1/2” - 2” / 10– 54mm
Run tube NS 1/2” - 4” / 15– 108mm
Max. wall-thickness See Capacity chart (11.1)
Materials Copper (Cu)
Cycle 1 min. 45 s
Rotation speed of
spindle
500 / 50 RPM
A-accentuated
equivalent level of
sound pressure
82,5 dB (A) Use ear
protectors!
Vibration less than 2,5 m/s2
Dimensions of the unit 22.4”(l) x 4.9” (h) x 7.1” (d)
570 (l) x 125 (h) x 180 (d) mm
Weight of the unit 11,9 lbs /5,4 kg
Supply voltage of the
unit
120V / 60Hz / 7,0AMPS
230V / 50Hz / 4,0A
110V /50Hz 8,4AMPS
13
