R6
Rearpanel features
R1) MAINS INPUT
(Power Supply): The BIG FOOT contains an internal power transformer, and comes
with a Power cord that should be connected to 230V-AC.
Always be certain to turn off the device before plugging in the power
cord.
MIDI cables should also be connected before start-up.
R2) MIDI OUT jack: As the BIG FOOT transmits and receives MIDI information simul-
taneously, a fully mounted 7-pin MIDI cable must be used.
T-Rex Engineering provides an 8 meter 7 pin MIDI-cable with every
BIG FOOT.
If the length is not sufcient, please contact your dealer.
R3) Volume #7
(Expression pedal inlet): This ” stereo jack allows for the connection of an expression pedal
that solely controls the volume.
T-Rex recommends Roland FV-200 expression pedals, as they are 100%
reliable. Using a Roland expression-pedal EV-5 is an alternative option.
R4) EXP1 and EXP2
(Expression pedal inlet): These ” stereo jacks allows for the connection of a second and third
expression pedal. These pedals control the so-called real-time-effects,
e.g. delay-time, reverb-reection etc.
NB:
As the expression pedal inlet is a stereo jack, a Y-cord is
required for connecting the IN/OUT jacks from the Roland
FV-200 pedal to the expression pedal inlet in the BIG FOOT.
R5) CTL 1: This ” mono jack allows for the connection of an external control
switch. It is the ideal place to hook up a momentary type footswitch
that lets you engage/disengage a function.
R1
R5
R2
R3
R2
R4
