TW20_NS20_EW20 Series Weighing Indicator Operation Manual REV:01
- 6 -
EW20
1. Keyboard
2. Preset keys
3. Indicator Holder
4. 4.3” LCD display
5. AC adapter jack
6. RS232 port
7. RJ45 LAN port
8. Load cell connector
4
5
6
7
8
1
2
3
