T Scale NS20 Series User Manual

TW20_NS20_EW20 Series Weighing Indicator Operation Manual REV:01
- 10 -
3. INSTALLATION
3.1 Unpacking
 Remove the scale from the carton.
 Remove the protective covering. Store the packaging and to use if you need to transport the scale later.
 Inspect the scale for damage.
 Make sure all components are included.
1. Indicator
2. Adaptor
3. Manual
3.2 Installation
 Place the Indicator on a table or use indicator holder to connect with stand.
 Connect the platform load cell cable in to the indicator load cell connector. Load cell connector is locating
back side of the indicator.
3.3 Load cell connections
 Connect the load cell cables to the terminal as shown below.
 It can connect four 350 ohm load cells.
 The load cell drive voltage is 5V DC ±5% between Excitation + and
Excitation -.
 Connect the dual load cell cables to the terminal as shown
below.(optional)
7Pin
Connection
Pin 1
Signal -
Pin 2
Signal +
Pin 3
Shield
Pin 4
Exc -
Pin 5
Sen -
Pin 6
Sen +
Pin 7
Exc +
9 Pin
Connection
1
Excitation +
2
Sense +
3
Shield
4
Sense -
5
Excitation -
6
NC
7
Signal -
8
Signal +
9
NC
7 Pin
Connection
1
Signal -
2
Signal +
3
Shield
4
Excitation -
5
Sense -
6
Sense +
7
Excitation +
