T Scale TW20 Series User Manual

TW20_NS20_EW20 Series Weighing Indicator Operation Manual REV:01
- 15 -
Icon
Name
Description
On/OFF key
 Press the key to turn the scale on
 Long press to turn the scale off
Print key
 Used to print weighing data in normal weighing mode
 Used to print reports when in report mode
Percentage key
 Used to enter percentage mode in normal weighing mode
Unit Weight key
 Used to store the known average piece weight of item
 Long press to change the average piece weight value of item
Sampling key
 Used to enter the counting operation
Product key
 Used to recall product information
 Long press to search product information from list
Menu key
 Used to enter parameter setting
 Long press to check the set parameter information
Local/Remote key
 Used to change weighing units
 Shift to capital letter / small letter when entering characters
 Long press to switch local scale to remote scale
to
Numeric and
alphabetic keys
 Input number in weighing mode
 Input numeric and alphabet in parameters and PLU setting
Decimal point key
 Used to input decimal point
Clear key
 Used to clear selected products and numeric keys
 When entering characters, short press to clear one bit, long press to
clear all
Zero key
 Used to zero the scale.
 Long press to exit other modes (counting or percentage mode) and back
to weighing mode
Tare key
 Used to perform a tare function, Subtracts weights.
Limit key
 Used to enter check weighing mode
 Long press to set HI and Low limits
Accumulation key
 Used to store the accumulation weights in memory
 Used to recall accumulation records
to
Direct PLU
(M1~M8 available
for TW20 )
 To recall direct PLU
 Long press to store direct PLU
