Problem
The machine is not set
level during operation.
Uneven stubble.
Stripes in the stubble.
Stubble too high.
Uneven swath.
Stubble not parallel with
ground.
Too little conditioning
effect.
Packing of crop on the
right hand and/or left
hand side.
Problem/Fault Analysis and Correction
Correction
Adjust the balancing springs.
Increase forward speed.
Increase the r.p.m. of the P.T.O./
engine speed.
Turn knives or replace them.
Adjust the balance springs.
Check the gearbox.
Change the inclination angle of the
cutterbar.
Remove high cut skids.
Note: The field must be clear of stones.
Increase the forward speed.
Fit throwing wings on the cutting
discs.
Adjust the conditioning rotor's
speed to 900 r.p.m.
Fit adjustable lower right hand con-
necting rod.
Adjust the conditioning rotor's
speed to 900 r.p.m.
Adjust deflector plates.
Adjust the lifting cylinders.
Move the front plate nearer to the
rotor.
Adjust the conditioning rotor's
speed to 900 r.p.m.
Fit straw dividers on the right hand
and/or left hand side.
See page
35
27 + 31
49
35
27 + 31
35
43
45
39
43
39
39
37
39
39
43
Possible cause
The cutterbar is not level with the
ground.
Forward speed too slow.
P.T.O. r.p.m. on the tractor is too
slow.
Knives too blunt or some knives
missing.
Machine is not properly balanced.
Wrong main gearbox fitted.
The angle of the cutterbar is not
ideal for the crop in question.
Cutterbar equipped with high cut
skids.
Packing of crop on the cutting
discs.
Cutterbar angle too small.
Conditioning rotor speed too slow.
Wrong adjustment of deflector
plates.
The machine lifting cylinders is not
adjusted correctly.
Too much distance between crim-
per plate and rotor.
Rotor speed too slow.
Long grass and grass lying down.
*)
