-21-
14.2 Control Variables
Pump will respond to external controls according to selected pump operating mode.
Consult proper pump operating manual for explanation.
1
Not all inputs are available in all modes.
2
External, Modbus and BACnet. Stop signals become active in night mode. Due to possible confusion,
use of night mode is discouraged while using external control.
3
Only available when pump is bus controlled.
4
Not available when pump is bus controlled.
5
Multiple limits can be set. Not available on all pumps.
6
Night mode is not independent regulation mode.
Symbol Regulation mode Module set point controls:
activeADAPT®
---
(RUN ONLY)
Proportional pressure Maximum head
Constant pressure Maximum head
Constant speed Speed (RPM)
--- Combined
5
(Web interface only)
Night mode
6
---
(RUN ONLY)
