Foreword
This service manual describes the composition of the Model GR-130EX-2 rough terrain crane, its adjustment
methods and hydraulic and electric circuit diagrams.
This service manual applies to the cranes with the specification numbers given below. Check the specification
number on the nameplate of your crane.
Read the separate service manuals, the operation manual and the parts catalog for repair and maintenance of
the crane in conjunction with this manual. If any part needs to be replaced, check the disassemble units and
sales units in the parts catalog before replacing them.
1. Applicable spec. and serial number
Spec. No. Applicable serial number
GR-130E-2-00103 FD3305--
Separate service manual
Separate Service Manual Publication No.
1 General Cautions WA01-0121E
2 Automatic Moment Limiter (AML-C) to be published
3 Multiplex data Transmitter (MDT-9) to be published
4
Torque Converter (EXEDY)
W561-0131E
Transmission (EXEDY)
5 Driving Axle (OKUBO GEAR) W563-0091E
Please note that, for product improvement, some changes which are not
covered in this manual may have been incorporated in the machine.
And please note that this manual may cover the functions and equipment
which are not equipped with your machine.
Please check your actual machine for repair and maintenance.
