42 Assembly/Disassembly Instructions T2004 Multi-Control Head System Manual
© Tait Electronics Limited May 2004
5 Assembly/Disassembly Instructions
This section provides mechanical parts information and disassembly
instructions for the control heads.
5.1 Mechanical Parts
The T2004 Multi-Control Head includes the following mechanical parts.
Please use the IPN number and description when ordering replacement
parts.
Note All PCB and cable components are specified separately. For infor-
mation for these items, refer to the sections listed below:
■ For PCB information, refer to Section 6, “X2H2xx PCB
Information”.
■ For external cable information, refer to Part A, Section 5, “System
Equipment Specifications”.
Item Description IPN Qty
1 Knob A3M2530 T2K SII 311-01042-01 1
2 Microphone with Grommet 252-00010-76 1
3 Panel Frt Scrn T2020/40/50 SII 316-06430-02 1
4 Volume Pot Nut part of 040-05100-20 1
5 Volume Pot Washer part of 040-05100-20 1
6 LCD Display 008-02029-00 1
7 Lightspreader 20 Bttn T2K SII 304-07036-02 1
8 Keypad SII International 311-03076-01(T2020) 311-03078-01(T2040) 1
9 Volume Pot 040-05100-20 1
10 Pot PCB part of 228-23722-xx 1
11 Microphone Connector 240-04021-61 1
12 Lens LCD Display T2K FM2/TR2 312-01046-05 1
13 Control Head PCB 228-23722-xx 1
14 Screw 4-20x3/8 P/P Trilobe-P BZ (Control Head Screws) 349-00010-22 2
15 Back Panel 316-02001-00 1
16 Screw 4-20x5/8 P/P Trilobe-P BZ (Remote Back Screws) 349-00010-24 4
17 Captive Nut M4 Pressed 352-00010-17 2
18 Remoting Connector Cover 316-85125-00 1
