Tait T2000 Series User Manual

44 Assembly/Disassembly Instructions T2004 Multi-Control Head System Manual
© Tait Electronics Limited May 2004
4. Carefully remove the LCD (6) and lens (12).
5. Lay the assembly on a horizontal surface, with the light spreader (7)
in place.
6. Remove the volume knob (1) and volume knob nut (4) to access the
lightspreader and keypad.
7. Before reassembly, the LCD and PCB edge connectors should be
wiped with alcohol.
Caution Take care to ensure the alcohol does not come into
contact with the coating on the lightspreader, as this
will dissolve on contact with alcohol.

Tait T2000 Series Specifications

General

IP Rating	IP54
Operating Temperature Range	-30°C to +60°C
Channel Spacing	12.5 kHz, 25 kHz
Number of Channels	Up to 256
Receiver Sensitivity	0.25μV for 12dB SINAD
Signalling	DTMF
