Tait T2000 Series User Manual

T2004 Multi-Control Head System Manual Part B T2004 Control Heads 67
May 2004 © Tait Electronics Ltd
5.1 X2AM01 Rev 008 Parts List
IPN 228-23721-01
Ref IPN Description
C1 015-27100-10 Cap Cer 0805 1m+80-20% Y5v 16v
C2 015-26100-08 Cap Cer 0805 100n 10% X7r 50v
C3 015-26100-08 Cap Cer 0805 100n 10% X7r 50v
C6 015-23100-01 Cap Cer 0805 100p 5% NPO 50v
C7 015-24100-08 Cap Cer 0805 1n 10% X7r 50v
C8 015-24100-08 Cap Cer 0805 1n 10% X7r 50v
C9 016-09100-01 Cap Elec SMD 100u 6.6*6.6 6.3v
C10 015-26100-08 Cap Cer 0805 100n 10% X7r 50v
C11 015-24100-08 Cap Cer 0805 1n 10% X7r 50v
C14 015-24100-08 Cap Cer 0805 1n 10% X7r 50v
C15 015-26100-08 Cap Cer 0805 100n 10% X7r 50v
C18 015-26100-08 Cap Cer 0805 100n 10% X7r 50v
C21 016-08100-01 Cap Elec SMD 10m 4*5.2 16v 20%
C26 015-22330-01 Cap Cer 0805 33p 5% NPO 50v
C36 015-22330-01 Cap Cer 0805 33p 5% NPO 50v
C39 015-23100-01 Cap Cer 0805 100p 5% NPO 50v
D1 001-10284-51 Diode SMD BZX284B5V1 Zensod110
R1 036-14180-00 Res M/F SMD 0805 1k8 5%
R2 036-15560-00 Res M/F SMD 0805 56k 5%
R3 036-14100-00 Res M/F SMD 0805 1k 5%
R4 036-14150-00 Res M/F SMD 0805 1k5 5%
R5 036-14150-00 Res M/F SMD 0805 1k5 5%
R7 036-15270-00 Res M/F SMD 0805 27k 5%
R8 036-12390-00 Res M/F SMD 0805 39e 5%
R9 036-15270-00 Res M/F SMD 0805 27k 5%
R10 036-15220-10 Res M/F SMD 0805 22k 1%
R12 036-15120-10 Res M/F SMD 0805 12k 1%
R13 036-15270-00 Res M/F SMD 0805 27k 5%
R17 036-15560-00 Res M/F SMD 0805 56k 5%
R18 036-15220-10 Res M/F SMD 0805 22k 1%
R25 036-14150-00 Res M/F SMD 0805 1k5 5%
R26 036-14150-00 Res M/F SMD 0805 1k5 5%
R27 036-13150-00 Res M/F SMD 0805 150e 5%
R28 036-13150-00 Res M/F SMD 0805 150e 5%
R38 036-14820-10 Res M/F SMD 0805 8k2 1%
R42 036-15270-00 Res M/F SMD 0805 27k 5%
SK1 240-10000-05 Conn SMD 8w 2r Skt M/Match
SK3 240-10000-05 Conn SMD 8w 2r Skt M/Match
T1 054-00010-20 Xmfr SMD Ct Etal2782
U1 002-10021-42 IC SMD TLE2142CD Opamp S08
U2 002-12951-00 IC SMD LP2951CM Adj Vltge Reg
U4 002-10004-83 IC SP483EEN RS485 Xcvr/Esd S08
U5 002-10004-83 IC SP483EEN RS485 Xcvr/Esd S08
219-02013-00 T2K 8way Loom Logic-Ctrl Hd
228-23721-01 Pcb T2020/40 M/Ctrl Hd Rad I/F
365-00011-54 Lbl White R1556/2 90*24mm
399-00010-51 Bag Plstc 75*100mm
399-00010-86 Bag Static Shlding 127x203mm
349-00020-32 Scrw M3*8mm T/T P/P Bz
353-00010-16 Wshr M3 Fibre 8mm Od*1.5mm
