Tait t2020 Service Manual

M2000-00 T2000-800 RF PCB 7.7.1
Copyright TEL 31/12/97
Ref Var IPN Description Ref Var IPN Description
IPN 220-01305-03
C1 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C2 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C3 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C100 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C104 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C106 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C107 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C108 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C109 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C110 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C124 015-21330-01 CAP CER 0805 CHIP 3P3 +/-0.25P NPO 50V
C125 015-21180-01 CAP CER 0805 CHIP 1P8 +/-0.25 NPO 50V
C126 015-21330-01 CAP CER 0805 CHIP 3P3 +/-0.25P NPO 50V
C127 015-21680-01 CAP CER 0805 CHIP 6P8 +/-0.25P NPO 50V
C128 015-22220-01 CAP CER 0805 CHIP 22P 5% NPO 50V
C129 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C130 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C133 015-22390-01 CAP CER 0805 CHIP 39P 5% NPO 50V
C134 015-21560-01 CAP CER 0805 CHIP 5P6 +/-0.25P NPO 50V
C135 015-22150-01 CAP CER 0805 CHIP 15P 5% NPO 50V
C136 015-21680-01 CAP CER 0805 CHIP 6P8 +/-0.25P NPO 50V
C137 015-23120-01 CAP CER 0805 CHIP 120P 5% NPO 50V
C138 015-21680-01 CAP CER 0805 CHIP 6P8 +/-0.25P NPO 50V
C139 015-22150-01 CAP CER 0805 CHIP 15P 5% NPO 50V
C140 015-21560-01 CAP CER 0805 CHIP 5P6 +/-0.25P NPO 50V
C141 015-22390-01 CAP CER 0805 CHIP 39P 5% NPO 50V
C142 015-21560-01 CAP CER 0805 CHIP 5P6 +/-0.25P NPO 50V
C149 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C158 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C174 020-58470-05 CAP ELECT AI RDL 47M 16V 6.3X7MM
C175 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C176 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C179 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C180 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C181 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C182 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C184 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C185 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C186 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C187 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C188 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C189 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C190 015-23470-08 CAP CER 0805 CHIP 470P 10% X7R 50V
C191 015-23560-08 CAP CER 0805 CHIP 560P 10% X7R 50V
C192 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C193 020-57470-10 CAP ELECT AI RDL 4U7 50V LO ESR
C194 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C195 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C197 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C198 015-21100-01 CAP CER 0805 CHIP 1PO +/-0.25P NPO 50V
C199 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C200 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C201 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C202 015-22220-01 CAP CER 0805 CHIP 22P 5% NPO 50V
C203 015-25220-08 CAP CER 0805 CHIP 22N 10% X7R 50V
C204 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C205 015-25220-08 CAP CER 0805 CHIP 22N 10% X7R 50V
C206 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C207 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C208 015-23100-01 CAP CER 0805 CHIP 100P 5% NPO 50V
C209 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C210 015-23100-01 CAP CER 0805 CHIP 100P 5% NPO 50V
C211 015-22560-01 CAP CER 0805 CHIP 56P 5% NPO 50V
CV212 028-02200-01 CAP TRIM 4/20P N750 TOP ADJ RED MUR TZ
C213 020-58470-05 CAP ELECT AI RDL 47M 16V 6.3X7MM
C214 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C215 020-57470-10 CAP ELECT AI RDL 4U7 50V LO ESR
C216 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C217 020-58470-05 CAP ELECT AI RDL 47M 16V 6.3X7MM
C218 020-57470-10 CAP ELECT AI RDL 4U7 50V LO ESR
C219 020-57470-10 CAP ELECT AI RDL 4U7 50V LO ESR
C220 022-55100-10 CAP MYLAR AI 10N 5% 63V POTTED
C221 022-57100-02 CAP MYLAR AI 1M 20% 50V POTTED
C222 022-06100-15 CAP MET POLYSTR 100N 5% 50V 5.6MM HI
C223 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C224 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C225 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C226 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C227 015-21560-01 CAP CER 0805 CHIP 5P6 +/-0.25P NPO 50V
C229 020-58470-05 CAP ELECT AI RDL 47M 16V 6.3X7MM
C230 015-22220-01 CAP CER 0805 CHIP 22P 5% NPO 50V
C231 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C232 015-21120-01 CAP CER 0805 CHIP 1P2 +/-0.25 NPO 50V
C233 020-57470-10 CAP ELECT AI RDL 4U7 50V LO ESR
C235 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C236 015-21330-01 CAP CER 0805 CHIP 3P3 +/-0.25P NPO 50V
C237 015-21330-01 CAP CER 0805 CHIP 3P3 +/-0.25P NPO 50V
C238 015-21390-01 CAP CER 0805 CHIP 3P9 +/-0.25P NPO 50V
C240 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C241 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C242 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C243 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C244 015-22560-01 CAP CER 0805 CHIP 56P 5% NPO 50V
C245 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C246 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C247 015-21270-01 CAP CER 0805 CHIP 2P7 +/-0.25P NPO 50V
C248 020-09100-07 CAP ELECT 100M 10V 6.3X7MM 5MM
C249 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C250 015-22220-01 CAP CER 0805 CHIP 22P 5% NPO 50V
C251 015-23120-01 CAP CER 0805 CHIP 120P 5% NPO 50V
C252 015-22180-01 CAP CER 0805 CHIP 18P 5% NPO 50V
C253 015-22120-01 CAP CER 0805 CHIP 12P 5% NPO 50V
C254 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C255 015-21270-01 CAP CER 0805 CHIP 2P7 +/-0.25P NPO 50V
C256 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C301 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C303 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C304 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C305 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C306 015-21390-01 CAP CER 0805 CHIP 3P9 +/-0.25P NPO 50V
C307 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C308 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C309 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C310 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C311 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C312 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C313 015-21470-01 CAP CER 0805 CHIP 4P7 +/-0.25P NPO 50V
C314 015-21470-01 CAP CER 0805 CHIP 4P7 +/-0.25P NPO 50V
C315 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C316 015-24100-08 CAP CER 0805 CHIP 1N 10% X7R 50V
C317 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C318 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C319 015-21330-01 CAP CER 0805 CHIP 3P3 +/-0.25P NPO 50V
C320 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C321 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
C322 015-06100-08 CAP CER 1206 CHIP 100N 10% X7R 50V
C324 015-25100-08 CAP CER 0805 CHIP 10N 10% X7R 50V
C325 015-22330-01 CAP CER 0805 CHIP 33P 5% NPO 50V
7.7 T2000-800 RF PCB
T2000-800 Parts List (IPN 220-01305-03)
Parts List Amendments
R258: Changed from 10
Ω
to 0
Ω
(IPN 036-10000-00) to improve power output (6/05/97)
Mechanical parts corrections: Delete IPN 362-00010-08 (insulating gasket)
Add IPN 240-02100-11 (BNC socket)
Add IPN 353-00020-12 (0.9mm flat washer)
