4 TBA0STU/TBA0STP CTU Operation Manual

Preface

Scope of Manual

This manual provides information on using the TBA0STU/TBA0STP base

station Calibration and Test Unit (CTU) with a Tait base station. It

describes the input and output connectors and controls available on the

CTU, and includes a description of the accessories supplied with the CTU.

A block diagram is also provided.

Enquiries and Comments

If you have any enquiries regarding this manual, or any comments,

suggestions and notifications of errors, please contact Technical Support

(refer to “Tait Contact Information” on page 2).

Updates of Manual and Equipment

In the interests of improving the performance, reliability or servicing of the

equipment, Tait Electronics Ltd reserves the right to update the equipment

or this manual or both without prior notice.

All information contained in this manual is the property of Tait Electronics

Ltd. All rights are reserved. This manual may not, in whole or in part, be

copied, photocopied, reproduced, translated, stored, or reduced to any

electronic medium or machine-readable form, without prior written

permission from Tait Electronics Ltd. All trade names referenced are the

service mark, trademark or registered trademark of the respective

manufacturers.

Disclaimer

There are no warranties extended or granted by this manual. Tait

Electronics Ltd accepts no responsibility for damage arising from use of the

information contained in the manual or of the equipment and software it

describes. It is the responsibility of the user to ensure that use of such

information, equipment and software complies with the laws, rules and

regulations of the applicable jurisdictions.
