16 Installation TB8100 Installation Guide
© Tait Electronics Limited February 2007
1.8.3 Auxiliary Support Bracket
TBAA03-13 auxiliary support brackets can be fitted to the rear of the
TB8100 subrack to provide additional mounting security. Figure 1.6 below
shows a standard TBAA03-13 bracket
b fitted in a typical Tait Electronics
cabinet
c. If you are not using a Tait cabinet, you may have to make your
own brackets to suit your installation.
Important Yo u must fit the auxiliary support brackets if you intend to
transport a cabinet fitted with a fully built-up TB8100 base
station.
We also recommend that you fit the brackets under the following
conditions:
■ when the installation is in an area prone to earthquakes
■ when third party equipment is installed hard up underneath the TB8100
subrack.
Figure 1.6 Auxiliary support bracket
c
b
