Table 2.2 Auxiliary connector (radio)—pins and signals
Pinout Pin Signal name Description Signal type
12 AUX GPI1 General purpose digital
input. Programmable
function
Digital,
3V3 CMOS.
5 AUX GPI2
4 AUX GPI3 General purpose input
(ignition sense)
3V3 levels.
Protected for
+13.8V.
10 AUX GPIO4 Programmable function and
direction
Pads available to fit a higher
power driver transistor on
GPIO4 line
Digital, 3V3
CMOS input;
open collector
output with
pullup
2 AUX GPIO5
9 AUX GPIO6
1 AUX GPIO7
11 AUX TXD Asynchronous serial port -
Transmit data
Digital,
3V3 CMOS
3 AUX RXD Asynchronous serial port -
Receive data
Digital,
3V3 CMOS
7 AUD TAP IN Programmable tap point into
the Rx or Tx audio chain.
DC-coupled
Analog
13 AUD TAP OUT Programmable tap point out
of the Rx or Tx audio chain.
DC-coupled
Analog
14 AUX MIC AUD Auxiliary microphone input.
Electret microphone biasing
provided. Dynamic
microphones are not
supported
Analog
6 RSSI Analog RSSI output Analog
8 +13V8 SW Switched 13.8V supply.
Supply is switched off when
radio body is switched off
Power
15 AGND Analog ground Ground
