14 Installing the Radio TM9100 Installation Guide
© Tait Electronics Limited August 2005
2 Installing the Radio
This section contains the following information:
mounting and removing the control head
selecting the mounting position
mounting the U-bracket
installing the antenna
connecting the power cable to the power source
connecting a remote speaker
connecting to the auxiliary connector (ignition signal,
emergency switch, external alert devices)
installing the radio
installing the microphone
checking the installation.
2.1 Mounting and Removing the Control Head
Important The control head contains devices which can be damaged
by static discharges. Always install or remove the control
head in a static-safe environment. For information on
antistatic precautions, go to the Electrostatic Discharge
Association (ESD) website, http://www.esda.org.
Mounting the
Control Head
The control head and its connection loom are delivered separately from the
radio body. Before installing the radio, the control head should be mounted
on the radio body.
The orientation of the radio body determines which way up the control
head is mounted on the radio body.
Note It may be required to mount the radio upside down to maintain a
gap of more than 3/8 inch (10mm) for air circulation between the
underside of the radio body and the mounting surface.
