TM9100 Mobiles: 110 W Mobile Installation Guide Installing the Radio 15
© Tait Electronics Limited October 2005
Important Protect the power cable from engine heat, sharp edges and
from being pinched or crushed.
2. Run the supplied power cable (or one with a higher current rating)
between the radio’s mounting position and the vehicle battery (12 V)
and cut it to length, allowing approximately 8 inches (20 cm) excess
at the radio end.
3. Cut the negative (black) and the positive (red) wires where the in-line
fuse holders will be placed (as close to the power source as possible).
Important Do not install the fuses until the installation is ready to be
checked. For more information, refer to “Checking the
Installation” on page 22.
4. Insert each end of the negative wire into each of the fuse
crimp-terminals and crimp them to force the metal contacts onto
the wires.
5. Push the two crimp-terminals into the clear plastic fuse cover. Close
the cover while the next steps are completed.
6. Repeat steps 4 and 5 for the positive wire.
7. Connect the negative wire to the battery ground terminal.
8. Connect the positive wire to the battery positive terminal.
Important Do not install the fuses until the installation is ready to be
checked. For more information, refer to “Checking the
Installation” on page 22.
4.4 Installing the Remote Control Head
1. Choose a suitable location for the control head.
2. Mount the Control Head according to the instructions supplied
(IPN: 402-00015-00). Make sure that you follow the warnings and
cautions in these instructions.
Note The remote control head back (TMAA03-03) has already been
fitted to the Control Head and the dual RJ-45 torso interface
(TMAC34-1T) has already been fitted to the radio body.)
3. Run the remote head cable (TMAA04-01) from the control head
location to the radio mounting location.
