58 TM8000 Encryption Midian Encryption Programming and Service Manual
June 2006 © Tait Electronics Limited
J1 not fitted in this application D3 1J6
J2 not fitted in this application D2 1J6
J3 not fitted in this application F5 1F13
J4 not fitted in this application C5 1D13
J5 240-00010-44 Skt 20w Hirose FH12 Flex Edge D6 1F14
LK1 036-10000-00 RES 0805 0R 1/8W D2 1J6
LK2 not normally fitted C3 1G8
LK3 not normally fitted G4 1F8
LK4 not normally fitted F4 1F8
LK5 not normally fitted B5 1E4
LK6 not normally fitted B1 1G13
LK7 not normally fitted C4 1F7
LK8 not normally fitted C4 1F9
LK9 036-10000-00 RES 0805 0R 1/8W C4 1F10
LK10 036-10000-00 RES 0805 0R 1/8W C4 1F11
LVI 002-11810-50 IC DS1810R-5 5V 5% MCU reset E5 1G14
Q1 000-10084-71 XSTR BC847BW NPN SOT323 D5 1G10
Q2 000-10084-71 XSTR BC847BW NPN SOT323 D5 1G11
Q3 000-10084-71 XSTR BC847BW NPN SOT323 D5 1G12
Q4 000-10084-71 XSTR BC847BW NPN SOT323 C5 1F11
Q5 000-10084-71 XSTR BC847BW NPN SOT323 C5 1E12
R11 038-16100-10 RES 0603 100k 1% 1/10W E4 1H2
R12 038-17221-10 RES 0603 2M21 1% 1/10W C3 1J2
R13 038-14560-00 RES 0603 5k6 5% 1/10W C2 1J3
R14 038-10000-00 RES 0603 0R C3 1H3
R15 038-10000-00 RES 0603 0R B2 1J3
R16 038-10000-00 RES 0603 0R B3 1J4
R17 038-15390-00 RES 0603 39k 5% 1/10W C2 1J4
R18 038-16100-10 RES 0603 100k 1% 1/10W C2 1K4
R19 038-15100-10 RES 0603 10k 1% 1/10W C2 1J4
R20 not fitted in this application D2 1J5
R11 038-16100-10 RES 0603 100k 1% 1/10W E4 1H2
R12 038-17221-10 RES 0603 2M21 1% 1/10W C3 1J2
R13 038-14560-00 RES 0603 5k6 5% 1/10W C2 1J3
R21 038-16100-10 RES 0603 100k 1% 1/10W B4 1H3
R23 038-10000-00 RES 0603 0R E5 1F3
R24 038-10000-00 RES 0603 0R C5 1F3
R25 038-10000-00 RES 0603 0R C5 1F3
R26 038-10000-00 RES 0603 0R B4 1F3
R27 038-10000-00 RES 0603 0R B4 1F3
R28 038-16220-00 RES 0603 220k 5% 1/10W B3 1E4
R29 038-10000-00 RES 0603 0R B3 1E4
R32 not fitted in this application G2 1G8
R33 not fitted in this application F2 1G8
R34 038-14470-10 Res 0603 4k7 1% 100ppm E5 1G10
R35 038-14820-00 RES 0603 8k2 5% 1/10W E5 1G10
R36 038-16220-00 RES 0603 220k 5% 1/10W D5 1G10
R37 038-16220-00 RES 0603 220k 5% 1/10W D5 1G11
R38 038-16220-00 RES 0603 220k 5% 1/10W C5 1G11
R39 038-16220-00 RES 0603 220k 5% 1/10W C5 1G12
R40 038-16220-00 RES 0603 220k 5% 1/10W D5 1G12
