Midian Encryption Programming and Service Manual TM8000 Encryption 59
June 2006 © Tait Electronics Limited
R43 038-15470-10 RES 0603 47k 1% 1/10W E4 1E9
R44 038-10000-00 RES 0603 0R E4 1D10
R46 038-16100-10 RES 0603 100k 1% 1/10W E4 1E10
R47 038-15220-10 RES 0603 22k 1% 1/10W D3 1D11
R48 038-15100-10 RES 0603 10k 1% 1/10W E3 1C10
R49 038-16100-10 RES 0603 100k 1% 1/10W E3 1E12
R50 038-10000-00 RES 0603 0R D3 1D12
R53 038-10000-00 RES 0603 0R F4 1C11
R54 038-15100-10 RES 0603 10k 1% 1/10W D3 1C12
R55 038-10000-00 RES 0603 0R G4 1B12
R56 038-15470-10 RES 0603 47k 1% 1/10W D4 1B12
R57 038-15100-10 RES 0603 10k 1% 1/10W D4 1B13
R58 038-16100-10 RES 0603 100k 1% 1/10W E4 1C13
R59 038-15220-10 RES 0603 22k 1% 1/10W E3 1C13
R60 038-15220-10 RES 0603 22k 1% 1/10W E3 1C13
SK1 240-00011-67 Skt 15w Drng Ra Slim Dsub 7912 D1 1J13
SK102 240-10000-11 Conn SMD 18w Skt M/Match B3 1F1
U1 002-10078-00 IC MC78M05CDT5V rgltr 0.5A B7 1D6
U2 002-10397-00 IC LM397 cmptr SOT23-5 C3 1B6 1J3
U3 not fitted in this application F2 1G4
U5 002-74910-41 IC 74V1G04 inv SC70 D2 1J5 1B7
U6 002-10040-53 IC 4053B break B4 make F4 1D9 1C11 1B8 1G2
U7 002-19140-00 IC TS914ID CMOS R2R OP-Amp E4
1D10 1B9 1C12
1D11 1D12
