To trim thread
84
Chapter 5
SQ01
2-5-2. How to operate
The following is the example of setting the number of consecutive jump code to "4".
(1) To open screen
(2) To select number of consecutive jump codes
2-6. To add thread trimming code to the design and trim thread (Data Edit "Insert")
This function always executes automatic thread trimming at the same position by adding thread trimming
code to the design. A stitch will be inserted before the selected stitch No. When this operation is performed
in the middle of embroidery, data set will be canceled. If the stitch with a length length is inserted, a design
will be displaced hereafter.
2-6-1. Explanation on the screen
1 Data Edit
Delete
1
2
3
4
5
6
7
8
9
10
0 0 Jump
84Stitch
83Stitch
11 5 Stitch
88Stitch
113Stitch
-11 2 Stitch
-12 -3 Stitch
-11 7 Stitch
-25 15 Stitch
Modify
Insert
Stitch No.
X data (Data to move the frame in X-axis
direction)
When the value is 8, the frame travel amount
is 0.8 mm.
Y data (Data to move the frame in Y-axis
direction)
When the value is 4, the frame travel amount
is 0.4 mm.
Function Code (p.251)
It is the code to indicate the role of the stitch.
To Next Page
