To trim thread
83
Chapter 5
1
2
3
4
5
6
7
8
9
10
11
PT10
(2) To select the number of upper thread breakage detecting times
When "N" is displayed, changing "N" to a value will set the detecting sensitivity in all needle bars to the
same.
(3) To select number of under thread breakage detecting times (unit)
2-5. To trim thread by the number of consecutive jump stitches (Jump Convert)
This function can be used to perform thread trimming in the middle of stitching and moving of the frame to
the next stitch by specifying the number of jump code without editing the design.
2-5-1. Explanation on the screen
1 Jump Convert
F1
3 NO/1-9
Frame Movement
A
Number of consecutive jump codes
NO: Not effected
1 to 9: Number of consecutive jump codes
How to move frame to next stitch
A: Batch
B: As data
To Next Page
