To trim thread
82
Chapter 5
UO04
The relationship between the number of detecting times and sensitivity is shown as follows.
[b] Setting how many consecutive times of detection of "Under (Step Ratio)" of [c] are regarded as
thread breakage to stop the machine
0: Not to stop even if under thread is broken
When idling the machine, set "Upper" and "Under (Unit)" to "0".
N: To stop if under thread is broken (the detecting sensitivity differs in each needle bar) (p.113)
2, 4, 6, 8: To stop if under thread is broken (Detecting sensitivity is same in all needle bar)
When selecting "4", the thread breakage will be detected after under thread breaks four
times continuously.
The relationship between the number of detecting times and sensitivity is shown as follows.
[c] Set sensitivity of [b]. Change this value according to the type of fabric and thread to use. It
enables to prevent mis-detection.
N: To stop if under thread is broken (the detecting sensitivity differs in each needle bar) (p.113)
30 to 100: To stop if under thread is broken (Detecting sensitivity is same in all needle bar)
The relationship between detecting ratio and sensitivity is shown as follows.
2-4-2. How to operate
The following is an example that the number of upper thread breakage detecting times is set to "2" and the
number of under thread breakage detecting times (unit) is set to "6".
(1) To open screen
30
Low
100
High
[Sensitivity]
