2. To trim thread
2-1. To trim thread manually (Thread breakage indicator lamp)
2-1-1. How to operate
In the main screen and in the state of operation possible, press the thread breakage indicator lamp
longer and release your finger. The thread cutting will be performed after the stop of the buzzer
2-2. To trim thread manually (Manual Thread Trimming)
2-2-1. Explanation on the screen
2-2-2. How to operate
When performing this operation, do not put your hands etc. near the needle or on the
machine table. Moving down of the needle bar could injure you.
: To trim thread
When performing this operation, do not put your hands etc. near the needle or on the
machine table. Moving down of the needle bar could injure you.
F1
A
AS
FB
BC
E
SET
D1 D2
F2 F3 F4
0Y:- 100.0
Thread breakage indicator lamp
