To trim thread
78
Chapter 5
XL03
The following is the example of executing thread trimming.
(1) To open screen
(2) To execute thread trimming
2-3. To trim thread automatically (ATH)
It is the setting to trim thread.
2-3-1. Explanation on the screen
[a] To trim thread automatically
YES: To trim
NO: Not to trim thread
Pressing SET key will move the
needle bar up/down and trim thread.
3 Manual Thread Trimming
F2
YES
9 ATH
YES/NO
N
M.shaft Inching after ATH
4
2
Return stitches
NO
1/2/T0/T1/T2/NO
Return Stitch Length
N
A
A/B/C/D/E
Thread trim length
9
Tie stitches
Tie Stitch Length
N
0.6 2.0 [mm]
0.6
2.0 [mm]
[b]
[c]
[d]
[e]
[f]
[g]
[a]
