To trim thread
79
Chapter 5
1
2
3
4
5
6
7
8
9
10
11
XL03
[b] Remaining length of upper thread after thread trimming (1 in the
right figure)
When upper thread remains on the fabric, select the value of "-".
If the thread does not link at the start of sewing due to short of
remaining length of upper thread, select the value of "+".
When "N" is displayed, the value differs in each needle bar.
Regarding the setting of needle bar unit, refer to detailed page. (p.113)
[c] Number of lowering the needle bar by slow operation at start after thread trimming or after data
set
[d] The number of return stitches at start of sewing
When "N" is displayed, the value differs in each needle bar. (p.113)
The more return stitches are, the less mis-stitching at start decreases.
[e] Stitch length of [d] described above
When "N" is displayed, the value differs in each needle bar. (p.113)
1
-2 +2
Short Long
0
T1: T2:
Without Return Stitches
Stitch at start of sewin
NO:
Triangle
1
2
3
T0:
One reciprocation
1 2
1:
Triangle + one
reciprocation
1
3
4 5
2
Two reciprocations
1 2
3 4
2:
Triangle + two
reciprocations
1
3
4 5
2
6 7
