To trim thread
80
Chapter 5
UO12
[f] Tie stitching at thread trimming
Setting more tie stitches prevent the thread from pulling out.
[g] Stitch length of [f] described above
When "N" is displayed, the value differs in each needle bar. (p.113)
2-3-2. How to operate
The following is the example that the thread is trimmed automatically, the thread trim length is set to "+2" and
"M.shaft Inching after ATH" is set to "3".
(1) To open screen
(2) To trim thread automatically
Not to perform tie stitching
Thread trimming position
A:
To perform tie stitching after lowering the
needle twice on the same position at the
end of the stitch
Thread trimming position
C:
To perform tie stitching (once)
Thread trimming position
B:
To perform tie stitching (twice)
Thread trimming position
D:
To switch B and D depending on the
direction of tie stitching
Thread trimming position (B or D)
E:
9 ATH
YES
