207
OPTIONS
Second Auxiliary Hydraulic
Switch
Move this switch to control the flow of the oil
in the second auxiliary hydraulic lines.
(C) .... Hydraulic oil flows to left auxiliary
line(c)
(D) .... Hydraulic oil flows to right auxiliary
line(d)
¡ When the safety lock lever is set to the
lock position, this control is locked.
Disconnecting the hydraulic circuits
1. Release the pressure remaining in the
lines then close the stop valve.
When equipped with accumulator :
Refer to page 204 “Releasing the residual
pressure”.
2. Disconnect the lines from ports (c) and (d).
3. Install the plugs.
Second Auxiliary Hydraulics
To Next Page
