59
CONTROLS
External Power Sockets (for EU)
W
ARNING
Only use applicable electric products with
these sockets.
for Beacon
Use these sockets as an external power
supply
. When using these sockets, be
careful not to exceed 12V / 10A.
To
use, raise the cap (1).
Applicable plug: BOSCH 0352321007
L2C0071
1
1
N0C008
Accessories
