Takeuchi TL12 User Manual

5-36
MAINTENANCE
EVERY 50 HOURS
1. Remove the bolts (a) and open the
radiator (b).
2. Remove the R-pin (e) from the stay (c).
3. Insert the stay (c) into the hole (d) to
secure the radiator (b).
4. Remove the negative terminal (1) from the
battery.
5. Remove the positive terminal (2) from the
battery.
6. Remove the double nut (3), and then
remove the battery cover (4) and the
battery clamp (5).
7. Remove the battery.
8. Remove any combustibles such as twigs,
dead leaves, oil and grease from the area
where the battery (6) was installed.
9. Install the battery (6) to the machine.
10. Install the battery cover (4) and the
battery clamp (5), and then secure them
with the double nut (3).
Double nut (3) tightening torque:
Lower nut, 2 N·m
Upper nut, 8 N·m
11. Install the positive terminal (2) to the
battery.
Removing any combustibles 12. Install the negative terminal (1) to the
battery.
13. Restore the radiator, and then close the
rear door.
