8-13
OPTIONS
INSTALLING OPTIONAL EQUIPMENT ON THE REAR OF THE MACHINE
INSTALLING OPTIONAL
EQUIPMENT ON THE REAR OF
THE MACHINE
If optional equipment is installed on the
rear of the machine, it may not satisfy the
specified gradeability. There is a risk of
tipping over if traveling on slopes with
optional equipment installed; ask your
sales or service dealer for advice.
The figure above illustrates the rear of the
machine without optional equipment
installed. Counterweights and other optional
equipment can be installed on the portions
enclosed by the dashed lines.
If you are not sure whether any optional
equipment is installed on the machine,
please contact your sales or service dealer.
