7-7
SPECIFICATIONS
MACHINE DIMENSIONS
<TL8>
Unit: mm (inch)
Item
Standard bucket
Rubber tracks
A Overall length 3430 (135.1)
B Overall length (without bucket) 2740 (107.8)
C Track base 1390 (54.7)
D Overall height 2130 (83.9)/2235 (88.0)*
E Ground clearance of undercarriage 310 (12.1)
F Overall width (without bucket)
400W 1660 (65.4)
320W 1580 (62.2)
G Track shoe width 400 (15.7)
H Body width 1430 (56.3)
J Canopy/Cab width 980 (38.6)/985 (38.7) *
K Bucket width 1675 (66.0)
L Bucket height 510 (20.0)
M Departure angle 30°
* : With a cab
<TL10>
Unit: mm (inch)
Item
Standard bucket
Rubber tracks
A Overall length 3755 (147.8)
B Overall length (without bucket) 3000 (118.1)
C Track base 1495 (58.9)
D Overall height 2270 (89.4)
E Ground clearance of undercarriage 325 (12.8)
F Overall width (without bucket) 1770 (69.7)
G Track shoe width 450 (17.7)
H Body width 1500 (59.1)
J Canopy/Cab width 985 (38.8)
K Bucket width 1880 (74.0)
L Bucket height 535 (21.1)
M Departure angle 30°
