Takeuchi TL12 User Manual

7-11
SPECIFICATIONS
OPERATING RANGES
<TL8>
Unit: mm (inch)
Item
Standard bucket
Rubber tracks
A Maximum raised height of bucket 3905 (153.8)
B Bucket hinge pin height 3030 (119.3)
C Dumping clearance (at 39-degree forward tipping) 2370 (93.4)
D Dumping reach (at 39-degree forward tipping) 730 (28.8)
E Minimum turning radius (bucket outside) 2080 (82.0)
F Minimum turning radius (front side, without bucket) 1375 (54.1)
G Minimum turning radius (rear side) 1585 (62.4)
H Bucket roll back angle (on ground) 30°
<TL10>
Unit: mm (inch)
Item
Standard bucket
Rubber tracks
A Maximum raised height of bucket 4080 (160.6)
B Bucket hinge pin height 3120 (122.8)
C Dumping clearance (at 39-degree forward tipping) 2405 (94.7)
D Dumping reach (at 39-degree forward tipping) 875 (34.4)
E Minimum turning radius (bucket outside) 2295 (90.4)
F Minimum turning radius (front side, without bucket) 1500 (59.1)
G Minimum turning radius (rear side) 1685 (66.3)
H Bucket roll back angle (on ground) 31°
<TL12>
Unit: mm (inch)
Item
Standard bucket
Rubber tracks
A Maximum raised height of bucket 4245 (167.1)
B Bucket hinge pin height 3205 (126.2)
C Dumping clearance (at 39-degree forward tipping) 2430 (95.7)
D Dumping reach (at 39-degree forward tipping) 985 (38.8)
E Minimum turning radius (bucket outside) 2435 (95.9)
F Minimum turning radius(front side, without bucket) 1560 (61.4)
G Minimum turning radius (rear side) 1755 (69.1)
H Bucket roll back angle (on ground) 31°
