Takex F71 Series - Dimensions (in mm); M8 connector type

Cord-Connected Type
■ Dimensions (in mm)
11
8
M8 connector
Amplifier
F70A/F70 Series
F 71 Series
(Common)
M8 connector type
(For dimensions of connector cords, see p. 23.)
Receiver
Transmitter
5
9
9
16
16
21
(21)
11.5 36.5
2-φ3.2×5.2 oval hole
2-φ3.2 hole
Mounting bracket
φ
4.8 cord (2 m in length)
3
4.7
4
8
4603
30
For dimensions of fiber optic cables, see pp. 67-.
