Takex F71 Series - M8 Connector Type IO Specification;Pin Arrangement;Lead Colors; Dimensions of cord with M8 connector (optional) (in mm)

F71RKPN
F71GKPN
F71BKPN
F71WKPN
F71RHKPN
F71GHKPN
F71BHKPN
F71WHKPN
Output circuit diagramModel
NPN output type
F70RK
F70GK
F70BK
F70WK
■ Input/Output Circuit and Connection
■ M8 Connector Type IO Specification/Pin Arrangement/Lead Colors
F71R
F71G
F71B
F71W
F71RH
F71GH
F71BH
F71WH
F71RK
F71GK
F71BK
F71WK
F71RHK
F71GHK
F71BHK
F71WHK
●
Dimensions of cord with M8 connector (optional) (in mm)
2000
30.7
22.5
Color: black
55
7
φ9
FBC-4R2S (straight)
2000
Color: black
5523
φ9
23.7
16
7
FBC-4R2L (angled)
PNP output type
F71RPN
F71GPN
F71BPN
F71WPN
F71RHPN
F71GHPN
F71BHPN
F71WHPN
Internal circuit
Brown: 12-24 VDC
Black: OUT PUT
Blue: 0V
Orange: STB OUT
Internal circuit
Brown: 12-24 VDC
Black: OUT PUT
Blue: 0V
Orange: STB OUT
13
42
White
Black
Blue
Brown
N.C (unused)
Control output
0V
12-24 VDC
F70A” −J”
13
42
White
Black
Blue
Brown
Stability output
Control output
0V
12-24 VDC
F71” −J”
13
42
White
Black
Blue
Brown
External teaching output
Control output
0V
12-24 VDC
F70” −JE”
13
42
White
Black
Blue
Brown
Stability output
Control output
0V
12-24 VDC
F70” −JS”
