41
DIAGRAM 1 - PARTS LIST
DIAG
LOC.
PART
NO.
QTY
REQ
DESCRIPTION
DIAG
LOC.
PART
NO.
QTY
REQ
DESCRIPTION
1
169573 1 Cart Assy (Incl. Items 2-4)
- - 169583 1
Cutting Head Assy (Incl. Items 46–49,51-56)
2 169576 Conveyor Cart w/ V-Top (only) 46 171032 1 Motor Base, B-Cap (only)
3 030822 4 Cart Wheel (only) - - 161730 2 Bearing Cap Assy (Incl. 47-49) (Qty 2 req’d)
4 032366 4 Nut, KEPS, 5/16”-18 47 189661 2 Cap Bearing
- - 030049 1 Cart Wheels, Set/4 (Incl. items 3 - 4) 48 020785 4 Lockwasher, Split 5/16”
5 051000 1 Rip Guide (Incl. Item 7) 49 020441 4 Capscrew, Hex Hd., 5/16” - 18 x 1-3/4”
6 189737 1 T-Knob, 1/4-20 x 1"
7 051195 1
Pan Assy, Blue (Incl. 8 – 15)
50 052004 1
Blade Shaft Assembly (Incl. Items 51–56)
* * 169889 1
Pan Assy, SS (Incl. 8** – 15)
51 052006 1 Blade Shaft
8 051196 1 Pan, Blue (only) 52 071081 2 Bearing
* * 169506 1 Pan, SS (only) 53 071110 1 Spring Washer
9 160965 2 Rail – Z/P 54 169522 1 Inner Collar
* * 169788 2 Rail– R/L, SS 55 169523 1 Outer Collar
10 020301 6 Capscrew, Hex Head, 1/4" – 20 x 5/8" 56 020176 1 Nut, Hex Jam Thin, 5/8” – 18
* * 189115 6 Capscrew, Hex Head, 1/4"–20 x 5/8" SS 57 020060 1 Key, 3/16” Sq. x 1”
11 020195 6 Locknut, Fiber, ¼” – 20 58 68822 1 Pulley, Arbor: 6GJ1.75-.627 w/SS,
* * 189116 6 Locknut, Fiber, ¼” – 20 SS (For 1-1/2HP, 115V/60/1)
12 051068 1 Rail Support {58a} 161696 1 Pulley, Arbor: 2G3V2.0 -.625 w/SS,
13 030386 1 Drain Plug (For 1-1/2HP, 115/230V/60/1)
14 052130 1 Decal, TARGET (Pan front) [58b] 058002 1 Pulley, Arbor: 1G3V1.9 w/SS,
* * 187070 1 Decal: TARGET (Pan front) (For 1HP, 240V/50/1)
15 169282 2 Decal: TILEMATIC (Pan sides) 59 58964 1 V-Belt: Poly 280J6, (For 1-1/2HP, 115V/60/1)
* * 178966 2 Decal: TILEMATIC (Pan sides) [59a] 058020 2 V-Belt: 3VX280, (For 1-1/2HP, 115/230V/60/1)
16 051063 1
Frame Assembly (Items 17 - 22)
[59b] 047455 1 V-Belt: 3VX300, (For 1HP, 240V/50/1)
17 051064 2
Pan Stop Assembly, (Items 18 & 19)
60 172101 1 Pulley, Motor: 6GJ2.8 w/SS,
18 051061 2 Pan Stop (For 1.5HP, 115V/60/1)
19 051065 4 Plastic Tab [60a] 030906 1 Pulley, Motor: 2G3V2.25 w/SS,
20 020784 2 Lockwasher, Split, 1/4" (For 1.5HP 115/230V/60/1)
21 020762 2 Washer, Flat ¼” [60b] 058052 1 Pulley, Motor: 1G3V3.67 w/SS,
22 020489 2 Screw, Hex Hd, Self-Tapping 1/4" – 20 x 3/4" (For 1HP, 240V/50/1)
23 020318 1 Capscrew, Hex Hd., 5/16” - 18 x 2-1/4” 61 020060 1 Key, 3/16” Sq. x 1”
24 020742 1 Washer, Flat, 5/16” 62 169422 1 Motor: 1.5HP-HT, 1725 RPM, 115V/60/1
25 020197 1 Locknut, Fiber, 5/16” – 18 A 001501 1 Motor Switch (169422)
26 169486 1 Knob, 5/16” – 18 x 1” B 169492 1 Manual Reset Overload (169422)
27 020742 2 Washer, Flat 5/16” - - 169493 1 Capacitor, Start (169422)
28 169527 1 Lockbar, Depth-Limiting - - 169494 1 Capacitor, Run (169422)
29 161641 1 Wrench [62a] 000605 1 Motor: 1-1/2 HP, 3450 RPM, 115/230V/60/1
30 043260 2 Set Collar 1” Dia. - - 161581 1 Motor Switch (000605)
31 050218 1
Water Pump Assy, 115V 60 Hz (Standard)
A1 032080 1 Switch, Housing & Wiring Assy (Incl. 161581)
G100 (Incl. Items 32-33)
A2 020741 4 Washer, Flat ¼”
161049 1 G100 Water Pump Repair Kit A3 020489 2 Screw, Sheet Metal, ¼” - 20 x ¾”
[31] 161316 1
Water Pump Assy, 115V 60Hz (Heavy Duty)
- - 030141 1 Dual Voltage Switch (000605)
G300, (Incl. Items 32 & 33)
- - 000873 1 Manual Reset Switch (000605)
[31] 050216 1
Water Pump Assy, 230V 50/60Hz
- - 189117 1 Capacitor, Start (000605)
G300, (Incl. Items 32 & 33)
[62b] 000503 1 Motor: 1 HP, 1425 RPM, 240V/50/1
032124 1 G300 Water Pump Repair Kit 001501 1 Motor Switch (000503)
32 197237 1 Hose Barb ¼” FPT x ¼” OD 63 178825 4 Flange Bolt, 5/16” - 18 x 1”
33 161134 1 Valve, Flow Control 64 020197 4 Locknut, Fiber, 5/16” – 18
34 169563 1
Water Tube Assy: ¼” Y x 32”
65 169580 1
Blade Guard Assy (Incl. 66 - 74)
35 169581 1
Belt Guard Assy (Incl. 36 - 44)
66 169532 1 Blade Guard (only)
36 051131 1 Belt Guard (only) 67 169365 1 Splash Guard
37 189661 2 Flange Bolt, ¼” - 20 x ½” 68 169366 1 Screw, Self-Tapping #8 x 3/8”
38 178825 1 Flange Bolt, 5/16” - 18 x 1” 69 020739 1 Washer, Flat #10
39 020197 1 Locknut, Fiber, 5/16” – 18 70 163248 1 Rubber Sponge Strip
40 187043 1 Decal: Warning (Belt Guard – Top) 71 020126 1 Carriage Bolt, 5/16” -18 x 2-1/2”
41 197108 1 Decal: Target (Belt Guard – Side) 72 020763 1 Washer, Flat 5/16”
* * 178963 1 Decal: TARGET (Belt Guard – Side) 73 020245 1 Locknut, Wing 5/16” – 18
42 169499 1 Belt Guard Bracket 74 052146 1 Decal: Tile Saw (Blade Guard – Side)
43 178826 2 Flange Bolt, ¼” – 20 x ¾” 75 - - - - - 1 Blade: 10” (254mm) - TARGET
44 020195 2 Locknut, Fiber, ¼” – 20 76 169773 2 Bushing, Pivot (For Pivot Head Version ONLY)
45
** These items are for TileMatic saws with SS Pan & Rails.
