Connecting with a computer
Use the included USB cable to connect the unit with a computer
as shown in the illustration.
CAUTION
Some USB devices use the USB bus frequently. In order to
avoid dropouts in the audio signal, clicking noises and other
problems, we strongly recommend that you do not connect
any other USB devices besides mice and computer keyboards
to the same computer when using this unit.
Connecting microphones
Connect a microphone to one of the two microphone inputs
(MIC) on the rear panel. You can use either the XLR connector
or the standard TRS jack. If microphones are connected to
both inputs, the signal from the microphone connected to the
standard TRS jack receives priority and the signal from the
microphone connected to the XLR connector is cut.
To activate the microphone input, set the switch on the rear
panel to MIC. When using a MIC input, do not connect anything
to the GUITAR IN jack on the front panel.
NOTE
This unit does not provide phantom power. To use a
condenser mic that requires power, use an external phantom
power source.
Connecting guitars
Connect a guitar or bass to the GUITAR IN jack on the front
panel.
The GUITAR IN jack receives priority when something is
plugged into it, and signals from other inputs are cut off
regardless of the input switch setting.
3 – Connections
