1.0 MEANING OF SIGNAL WORDS
A safety related message is identified by a safety alert symbol and a signal word to indicate the level of risk involved
with a particular hazard. Per ANSI standard Z535.4-1998 the definitions of the three signal words are as follows:
DANGER
CAUTION
WARNING
DANGER indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury.
TABLE OF CONTENTS
©Copyright Task Force Tips, Inc. 2002-2006
2.0 SAFETY
DANGER
Do not use AC current to operate the Ball Intake Valve RC or the Jumbo Ball Intake Valve RC. The
Ball Intake Valve RC and the Jumbo Ball Intake Valve RC are 12 or 24VDC systems ONLY! Using the
wrong power source could cause electrocution, resulting in death or serious injury.
WARNING
Kinks in supply hose may reduce water flow and cause injury or death to persons dependant on
water flow. When this valve is used on a hydrant or fire truck it is recommended that it be used with
an elbow to minimize risk of hoseline kinks.
WARNING
Injury or death can result from burst hoses and fittings. Be sure the pressure relief valve is set at
the proper pressure for the type of hose and equipment you are using. See NFPA 1961 and NFPA
1962.
WARNING
This equipment is intended for use by trained personnel for firefighting. Its use for other purposes
may involve hazards not addressed by this manual. See appropriate guidance and training to
reduce risk of injury.
1.0
2.0
3.0
3.1
3.2
3.3
4.0
4.1
4.2
4.3
4.4
4.5
5.0
5.1
5.2
5.3
5.4
MEANING OF SIGNAL WORDS
SAFETY
GENERAL INFORMATION
SPECIFICATIONS
CORROSION
USE WITH SALT WATER
INSTALLATION
MOUNTING ON TRUCK
RC INSTALLATION AND WIRING
CHANGING HANDWHEEL TO LEFT SIDE
CHANGING HANDWHEEL TO LEFT SIDE RC
RC MANUAL OVERRIDE
USE
INTAKE ELBOW
VALVE POSITION INDICATOR
STORZ SUCTION GASKET REQUEST
BALL INTAKE VALVE RC OPERATION
6.0
7.0
7.1
7.2
8.0
9.0
10.0
11.0
12.0
13.0
AIR VENT AND WATER DRAIN
PRESSURE RELIEF VALVE
SETTING PRESSURE
FLOW vs. PRESSURE CURVE
DRAWINGS AND PARTS LISTS
TROUBLE SHOOTING
MAINTENANCE
BALL INTAKE VALVE PRESSURE LOSS
TEMPLATES
WARRANTY
The member companies of FEMSA that provide emergency response
equipment and services want responders to know and understand the
following:
1. Firefighting and Emergency Response are inherently dangerous
activities requiring proper training in their hazards and the use of extreme
caution at all times.
2. It is your responsibility to read and understand any user's instructions,
including purpose and limitations, provided with any piece of equipment
you may be called upon to use.
3. It is your responsibility to know that you have been properly trained in
Firefighting and /or Emergency Response and in the use, precautions,
and care of any equipment you may be called upon to use.
4. It is your responsibility to be in proper physical condition and to maintain
the personal skill level required to operate any equipment you may be
called upon to use.
5. It is your responsibility to know that your equipment is in operable
condition and has been maintained in accordance with the
manufacturer’s instructions.
6. Failure to follow these guidelines may result in death, burns or other
severe injury.
DANGER
PERSONAL RESPONSIBILITY CODE
Fire and Emergency Manufacturers and Services Association, Inc.
P.O. Box 147, Lynnfield, MA 01940 • www.FEMSA.org
FEMSA
To Next Page
