Tattile ANPR MOBILE Series User Manual

 3GeneralCharacteristics
RMM_00029_09 14 / 42 ANPR Mobile
3.3.2 Power Supply, Ethernet and strobe Connector


Thetypeofthepowersupplyconnectoris:M168PoleMale.
 Matingpartincludedinthepackage.



Figure4: Powersupplypinoutconnector 

PIN Signalname Description
1+12Vdc Powersupply
2TxP Ethernet
3RxP Ethernet
4StrobeOut OutputStrobe
5TxN Ethernet
6GND Ground(powersupply)
7RxN Ethernet
8StrobeGND GNDOutputStrobe

Table5: Powersupply,Ethern etandstrobeconnector


 MatingpartM168PoleFemaleincludedinthepackage.
  
Figure5:Matingpinoutconnector


