9.3 Parts list
No Qty. Part number Description
1 1 HTF188P-BD Console
2 1 HTHA001 Safe key set
3 4 SK-299 Truss hex screw
4 1 XL-1284B Control cable (lower)
5 1 P-1066L Handrail upper cover (left)
6 1 P-1066R Handrail upper cover (right)
7 2 NO-2405 Handrail upper cover xture
9 2 SCK4-10 Truss philips self tapping screw Ø4x10
10 1 P-1065L Handrail lower cover (left)
11 1 P-1065R Handrail lower cover (right)
12 7 SMM4-16 Washer philips self tapping drill screw Ø4x16
13 2 SCI5-25 Truss philips self tapping screw Ø5x25
14 1 JTCA011A Upright pipe(left)
15 1 JTCB011A Upright pipe(right)
16 1 JTDA012 Handle pipe(left)
17 1 JTDA013 Handle pipe(right)
18 2 PCA-1-1/2-001 Cape Ø1-1/2"x1.5t
19 2 PFM-005 PVC foam tube
20 1 P-1045 Upper cover
21 6 P-1064 Plastic cover for screws
22 1 XM-118 Motor
23 4 SGA10-25I CKS hex screw M10xP1.5x25
24 4 SPB10 Spring washer M10
25 4 SPA100-200-30 Washer philips self tapping drill screw Ø10xØ20x3.0t
26 1 XM-121 Incline motor
27 1 SK-439 CKS hex screw M10xP1.5x40
28 3 SOC10 Nylon nut M10xP1.5
29 1 CA-240J10 Motor bel
30 1 XRB-013-002 Controlle
31 7 SCE5-12 Truss philips screw M5xP0.8x12
33 1 SOA10 Allen nut M10xP1.5
