TAWI VM50 - Page 3

03
Model VM30 VM40 VM50 VM60 VM80 VM100
Lifting
capacity
(kg)
30 40 50 60 80 100
Lift tube ø
(mm)
100 120 140 160 180 200
Stroke (mm) 1800/2600 1800/2600 1800/2600 1800/2600 1800/2600 1700/2400
Lift tube
length (mm)
2500/4000 2500/4000 2500/4000 2500/4000 2500/4000 2500/4000
Noise level,
Idle (dB)
73 76 76 76 76 78
Noise level,
In operation
(dB)
73 75 75 78 78 79
Model VM120 VM180 VM270
Lifting
capacity
(kg)
120 180 270
Lift tube ø
(mm)
230 250 300
Stroke (mm) 1700/2400 1500 1500
Lift tube
length (mm)
2500/4000 2500 2500
Noise level,
Idle (dB)
78 78 78
Noise level,
In operation
(dB)
79 79 79
Up and
down
motions
Variable speed - max 1 m/s (adjustable for light loads).
The max lifting capacity specied above are valid for standard congurations of the
lifters. Check the sticker on the lifter for applicable max load.
This table presents information about each model.
