21
Models 702/741/772 Operating Procedures
080324
Repeat these steps for the second freezing cylinder
on the Model 772.
Step 4
Remove the front drip tray and the splash shield.
Brush Cleaning
Step 1
Prepare a sink with an approved cleaning solution (ex-
amples: Kay-5R or Stera--SheenR). USE WARM
W ATER AND FOLLOW THE MANUFACTURER’S
SPECIFICATIONS
If an approved cleaner other than Kay-5R or Stera--
SheenR is used, dilute it according to the label instruc-
tions. IMPORTANT: Follow the label directions. Too
STRONG of a solution can cause parts damage. Too
MILD of a solution will not provide adequate cleaning.
Make sure all brushes provided with the freezer are
available for brush cleaning.
Step 2
Remove the seal(s) from the drive shaft(s).
Step 3
From the freezer door(s) remove:
S the gasket(s)
S the front bearing(s)
S the design cap(s)
S the draw valve(s)
Remove all o-rings.
Note: To remove o-rings, use a single service towel to
grasp the o-ring. Apply pressure in an upward direction
until the o-ring pops out of its groove. With the other
hand, push the top of the o-ring forward. It will roll out
of the groove and can be easily removed. If there is
more than one o-ring to be removed, always remove
the rear o-ring first. This will allow the o-ring to slide
over the forward rings without falling into the open
grooves.
Step 4
Thoroughly brush clean all disassembled parts in the
cleaning solution, making sure all lubricant and mix film
is removed. Take particular care to brush clean the
draw valve core in the freezer door(s). Place all the
cleaned parts on a clean dry surface to air dry
overnight.
Step 5
Return to the freezer with a small amount of cleaning
solution. With the black bristle brush, brush clean the
rear shell bearing(s) at the back of the freezing
cylinder(s).
Figure 25
Step 6
Wipe clean all exterior surfaces of the freezer.
