Taylor 772 Service Manual

 $YDLODEOH 6HSDUDWHO\

3DUWV /LVW 0RGHOV 
'(6&5,37,21 3$576
83'$7(
5(0$5.6:$55
&/$66

47<

47<

47<
3$57
180%(5
50Hz
BELT-AX46 023027 2 000
BELT-AX38 023873 2 000 REPLACES 023874 - EFFECTIVE 5/17/98
BELT-AX39 023874 4 000
BLOCK-TERMINAL 2 POLE 115 039421 1 1 4 103
BLOCK-TERMINAL-7 POLE GREEN 024156 1 1 2 103
COMPRESSOR RS80C1E-CAZ-224 - COPELAND 051958- 1 512 J9010000/UP 137
+CAPACITOR-RUN- 20UF/370V 023606 1 103 220/240-50-1
+CAPACITOR-START-64/77UF/250V 051960 1 103 220/240-50-1
+RELAY-START-COMPRESSOR 051957-40 1 103 220/240-50-1
COMPRESSOR L61B562BBKB - BRISTOL 048727- 1 512 PRIOR TO J9010000
+CAPACITOR-RUN- 15UF/370V 027087 1 103 220/240-50-1
+CAPACITOR-START-161-193UF/25 031790 1 103 220/240-50-1
+RELAY-START-COMPRESSOR 048766 1 103 220/240-50-1
COMPRESSOR AHA2490ZXC-AH556J - TECUMSEH 047519- 1 512
+CAPACITOR-RUN- 35UF/370V 029439 103 220/240-50-1
+CAPACITOR-START-135-155UF/330V 036048 103 220/240-50-1
+RELAY-START-COMPRESSOR 036047 1 103 220/240-50-1
COMPRESSOR L63A113BBKA - BRISTOL 048259- 2 512
+CAPACITOR-RUN- 25UF/370VA 023739 2 103 220/240-50-1
+CAPACITOR-START-161-193UF/25 031790 2 103 220/240-50-1
+RELAY-START-COMPRESSOR 038146 2 103 220/240-50-1
DIAGRAM-WIRING *702* 051286-40 1 000
DIAGRAM-WIRING 048342-40 1 000
DIAGRAM-WIRING *772* 051069-40 1 000
PULLEY-2AK32 X .626-.627 016251 1 000 GEAR
PULLEY-2AK64-5/8 BORE 039695 1 103 GEAR
PULLEY-2AK74-5/8 027822 2 103 GEAR
VIDEO-TRAIN FILM-DUALMASTER/SH 043568-PAL 1 1 1 000
