Taylor C835 - Manifold Assembly - X73109-02 (C845)

158
Parts
McDonald's Intelligap Grills
Manifold Assembly - X73109-02 (C845)
Figure 94
ITEM DESCRIPTION PART NO.
1 ELBOW-3/8 MPT X 5/16 076370
2 VALVE-GAS REDUNDANT 3-1/2
WC
079329-02
3 NIPPLE-3/8 MPT CLOSE BLK 076343
4 PLUG-3/8MPT-BLACK 078907
ITEM DESCRIPTION PART NO.
5 FITTING-CROSS 3/8FPT-BLACK 078906
6 NIPPLE-3/8"X5-1/2 BLACK PIPE 073110
7 TEE-3/8 FP BLACK PIPE 078980
8 FITTING-REDUCER-1/2FPT-
3/8FP
077364
