Taylor C844 Service Manual

+ Available Separately, NNN = Not a Service Item
172
Parts List
McDonald's Intelligap Grills
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C844
-75
QTY.
C842
-78
QTY.
C842
-75
QTY.
C842
-60
QTY.
C842
-23
QTY.
C834
-75
QTY.
C832
-75
QTY.
C832
-28
QTY.
C832
-23
PART
NUMBER
FUSE-4 AMP BK/MDL-4-R 079837-040 1 1 1 1 1 1 000
+HOLDER-FUSE-15 A, 250 V 076299 1 1 1 1 1 1 103
FUSE-6 AMP. 076301 1 1 1 1 1 1 1 000
GASKET-BRAIDED-HI TEMP R70113 10' 10' 10' 000
GASKET-GORE-TEX .250 DIA - NA 000 USE - R700033 SEALANT
GUIDE-CHECKOUT INTELLIGAP ELEC 072941-MCD 1 1 1 1 1 1 1 1 000
GUIDE-PATTY PLACEMNT 072912 1 1 1 1 1 103
GUARD-LENSE 075288 2 2 3 3 3 3 103
+LABEL-CONTROL PANEL-INTL SYMBL 075699-SYM 1 000
HANDLE-PLATEN *C834*
(SMALLER THAN 072472)
083474 2 C834 4/24/14 & UP -60 & -75
HANDLE-PLATEN *C832/C842* 072472 2 2 2 2 3 3 3 3 103
HARNESS A.-CNTL BOX X74157 1 1 1 1 103 S/N K7120000 & UP
HARNESS A.-COMP. VALVE X72743 1 1 1 1 1 103 S/N K7120000 & UP -
REPLACES X72854
HARNESS A.-COMP. VALVE *C832* X73145 1 1 1 1 103
HARNESS A.-COMP/TB X79503 1 1 1 1 103
HARNESS A.-COMP/TB X72854 1 1 1 1 1 103 S/N K7110000 & PRIOR -
CONTROL A.-UPPER
HARNESS A.-MOTOR *C842* 073472 2 2 2 2 3 3 3 3 103
HARNESS A.-PCB *C842* 073473 2 2 2 2 3 3 3 3 103
HARNESS A.-RELAY/PCB *C832* 072525 2 2 103
HARNESS-PCB/GR SWITCH 072529 2 2 2 2 3 3 3 3 3 103 CONTROL A.-LOWER
HARNESS-PCB/LOGIC 072527 2 2 2 2 3 3 3 3 3 103 CONTROL A.-LOWER
HARNESS-SSR TO I/O 072626 3 3 3 3 3 103
HEATER-CAST 2300W *M22E/32* 075486 6 103
HEATER-CAST 2300W *M22E/3 075906 6 103
HEATER-CAST 2300W *M22E/32* 079585-26 6 103
HEATER-CAST 2300W *M34* 074187-26 6 103
HEATER-CAST 1900W 208V C842 072657-23 9 103
HEATER-CAST 1900W *C842* 220V 072657-21 9 9 103
HEATER-CAST 1633W 230V C842 072752-75 9 103
HEATER-CAST 1633W 230V C844 072769-75 9 103
STUD-HEATER MOUNT 076539 36 103
HINGE A.-M.P.DOOR-RIGHT X78348 1 1 1 1 1 1 1 1 1 103
HINGE A.-M.P. DOOR-LEFT X78349 1 1 1 1 1 1 1 1 1 103
